MN-0515JJWJ

This is a highly advanced, fully automated line designed to produce retail-ready multi-packs ("family packs") of wet wipes. It integrates two machines into one seamless operation.

Basic Info

CATEGORY: Used Wet Wipe Machine
This is a highly advanced, fully automated line designed to produce retail-ready multi-packs ("family packs") of wet wipes. It integrates two machines into one seamless operation.
1.Stage 1: Primary Sachet Production (High-Speed). A Vertical Form Fill Seal (VFFS) machine produces small, individual wet wipe packs (sachets).
1.Fabric is folded, cut, and stacked to a low count (5-10 pieces).
2.Each stack is precisely moistened and sealed into a small flat-pack.
3.This machine runs at very high speed to feed the secondary packer.
2.Stage 2: Automatic Collation & Secondary Multi-Packing. The finished single packs are then automatically grouped and put into a larger outer bag.
1.Sachets are transported via conveyor to the secondary packer.
2.An automated collation system counts and stacks the sachets into a pre-set group (e.g., 4, 6, 8, or 10 sachets).
3.The entire group is then inserted and sealed into a larger printed "master" bag by a Horizontal Form Fill Seal (HFFS) machine.

Detailed Info

Technical Data Sheet

Full-Automatic Wet Wipe Multi-Pack (Bag-in-Bag) Production Line (Used)

Model: MPW-400 Series (Multi-Pack Wipes) | Condition: Excellent, Used, High-Integration | YOM: 2018-2021 (Est.)

1. Fully Integrated Two-Stage Production Process

This is a highly advanced, fully automated line designed to produce retail-ready multi-packs ("family packs") of wet wipes. It integrates two machines into one seamless operation.

Stage 1: Primary Sachet Production (High-Speed). A Vertical Form Fill Seal (VFFS) machine produces small, individual wet wipe packs (sachets).

Fabric is folded, cut, and stacked to a low count (5-10 pieces).
Each stack is precisely moistened and sealed into a small flat-pack.
This machine runs at very high speed to feed the secondary packer.

Stage 2: Automatic Collation & Secondary Multi-Packing. The finished single packs are then automatically grouped and put into a larger outer bag.

Sachets are transported via conveyor to the secondary packer.
An automated collation system counts and stacks the sachets into a pre-set group (e.g., 4, 6, 8, or 10 sachets).
The entire group is then inserted and sealed into a larger printed "master" bag by a Horizontal Form Fill Seal (HFFS) machine.

2. Production Capacity & Performance

Attribute	Specification
Primary Production Speed (Single 5-10ct packs)	300 - 500 packs/minute (sachets)
Secondary Production Speed (Final Multi-Packs)	40 - 80 packs/minute (Example: 400 sachets/min ÷ 5 sachets/group = 80 multi-packs/min)
Primary Pack Count	Adjustable, 5 to 10 pieces per sachet.
Secondary Pack Count	Adjustable, 4 to 10 sachets per multi-pack bag.
Control System	Integrated PLC control with synchronized HMI touch screens for both stages. Servo motors ensure precise counting, stacking, and sealing.

3. Product & Material Specifications

Attribute	Specification
Finished Product Type	Value Multi-Packs / Family Packs of wet wipes. e.g., A large bag containing 8 smaller packs of 10 wipes each.
Applicable Non-woven Fabric	Spunlace, Air-laid paper, etc. (e.g., 35-60 gsm).
Applicable Packaging Film	Heat-sealable films for both primary sachets and secondary bags (e.g., BOPP, PE/OPP).
Primary Sachet Size (Approx.)	Length: 100-150 mm; Width: 60-80 mm
Secondary Multi-Pack Size (Approx.)	Length: 200-350 mm; Width: 150-250 mm; Height: 60-100 mm (Varies based on grouping configuration)
