Product Description: KIMBER Customized Baby Diaper Machine
The KIMBER Customized Baby Diaper Machine is a highly flexible and high-speed production line engineered to meet your specific market demands. It is expertly designed to manufacture a wide variety of diaper types using different raw materials, including:
I-shape classic baby diapers
T-shape baby diapers with elastic ears (2 or 4 ears)
Full-surround elastic waistband baby diapers
Your unique, custom-designed diaper shape
Main Technical Parameters
Technical Parameter | KIMBER Machine Specifications |
|---|---|
Designed Production Speed | 650 pcs/min (Customizable) |
Stable Production Speed | 500-600 pcs/min (or as per customer's design) |
Product Size | Fully Customizable According to Client's Design |
Finished Product Rate | ≥ 98% |
Machine Capacity | Approx. 200 KW (Excluding hot melt applicators & air compressor) |
Power Supply | 380V, 50HZ (Three-phase five-wire) |
Air Pressure | 0.6-0.8 Mpa |
Machine Size (L*W*H) | 30.0m * 7.0m * 3.5m |
Machine Weight | Approx. 35 Tons (Whole production line) |
Main Function Features
Full Servo Motor Drive with PLC control and user-friendly touch screen interface.
High-speed teeth-like crusher for excellent fluff pulp processing.
SAP (Super Absorbent Polymer) auto-adding system with precise amount control.
Servo-driven unwinding, auto-tension control, and auto-splicing for raw materials without stopping the machine.
Automatic rejection system for waste and unqualified products.
Automatic detection and alarm for material exhaustion or breakage.
Phase adjustment can be done during operation without stopping.
Automatic recording and counting of production data.
Modular design allowing for future upgrades and customization.
